Basic Switch Mode Supply
Project #79 · Member project

Basic Switch Mode Supply

ZS6RVC · Early 2022
Category
Power supplies
Version
—
Status
—
Difficulty
—
Built by members
0

About this build

This basic switch-mode supply is a flyback converter that turns 220 V AC mains into a regulated 12 V DC at up to 18 W continuous, with an 85 to 265 V input range and 65 kHz switching. It uses a DK124 controller with PC817 optocoupler and TL431 feedback, and a fuse, MOV and NTC protect the mains input. Built by ZS6RVC and based on a DigiKey maker project. Club members can download the article with schematic, single-sided PCB layout, transformer winding details and bill of materials.

Basic Switch Mode Supply
Basic Switch Mode Supply
Basic Switch Mode Supply
